The Automatic Tableting Machine Line SMPLF is a compact, versatile liquid filling solution available in SMPLF-ED 30, 60, and 120 configurations. It delivers 20 to 120 vials/bottles per minute depending on the liquid nature and fill volume (0.1 ml to 100 ml). With 1% single dose filling accuracy and HMI control, it is ideal for pharmaceutical liquid filling operations. Cap sizes supported: 20 mm, 25 mm, and 28 mm.
Automatic Tableting Machine Line SMPLF
Available Models
SMPLF-ED 30
SMPLF-ED 60
SMPLF-ED 120
Get a Custom Quote

Contact us for pricing & availability

Key Highlights

At-a-glance performance metrics
🚀
Output / Min
20–120 Vials/Bottles
💧
Fill Volume
0.1 ml to 100 ml
🎯
Filling Accuracy
1% on Single Dose
🔩
Cap Diameter
20, 25, 28 mm
Power Supply
440V 3Ph / 230V 1Ph
📦
Net Weight
550 Kgs
📋

Full Technical Specifications

SMPLF-ED Series
Description
Model SMPLF-ED 30, 60, 120
Output / Min
20/120 Vials/Bottles (Depending on liquid nature, fill size or volume)
Power Characteristics
440V, 3 Phase, 50 Hz, 4 Wire System / 230 VAC, 1 Phase, 50 Hz, 3 Core Wire
Fill Volume
0.1 ml to 100 ml
Filling Accuracy
1% on Single Dose
Cap Dia
20 mm, 25 mm, 28 mm
Net Weight
550 Kgs
Machine Length
1600 mm
Machine Width
1200 mm
Machine Height
1800 mm
